High Resolution Mobile Thermal Label Printer Drop Resistant 4 Inches Width

Brand Name : WOOSIM

Model Number : WSP-I450

Certification : CE,FCC,ROHS

Place of Origin : CHINA

MOQ : 1 pc

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 10000PCS/Month

Delivery Time : 5-8 work days

Packaging Details : carton, 8PCS/ carton

Printing method : Direct thermal line printing

Interface : Bluetooth Verv 4.0, USB 2.0

Resolution : 203dpi, 8dots/mm

Character : Font Size A: 12X24 Font Size B : 9X24 Font Size C : 8X16

Paper Roll : Thermal roll paper, (58mm wide, 50ø)

Printing width : 104mm

H/W Spec : MCU -RX : 32bit, FLASH : 8M bytes, RAM : 16M bytes

Battery : 2600MAH(MAX)

Sensor : Balck mark sensor, label sensor

SDK : Android, IOS sdk

Driver : Support

Contact Now

4 inches width Mobile industry drop resistant IP54 thermal bluetooth label printer

WSP-I450



- High speed (110mm/sec, MAX)

- High resolution(203dpi : 8dots/mm).

- UART(RS-232C or TTL), Bluetooth Ver3.0

- Wireless LAN (IEEE 802.11a/b/g/n)[option], USB [option] interface

Item Specification
Printing method Direct thermal line printing
Characters per line 92cpl (MAX)
Optional Characters Simplified/Traditional Chinese, Arabic, Cyrillic, Russian, Tukish, Greek, Japanese, Persian, Latin9 and Others upon request.
Character size Eng. : 9x24dots, 12x24dots
Kor. : 16x24dots [24x24dots]
Resolution 203dpi, 8dots/mm
Print width 4-inch (104mm, 832dots)
Printing speed 110mm/sec (MAX)
Dimensions (WxDxH) 150.9 x 136.4 (143.2) x 63.3 mm
Weight 596g [standard]
609g [MSR option]
Interface

· UART(RS-232C or TTL) Bluetooth Ver3.0

· Wireless LAN (IEEE 802.11a/b/g/n)[option]
· USB [option]
Paper supplied Thermal roll paper, (113mm wide, 50ø),
Paper thickness : 60±5㎛
Barcode 1-dimension : Code128, Code39, I2/5, Code93, UPC-A, UPC-E,
EAN8, EAN13, CODABAR
2-dimension : PDF417, QR Code, DATA Matrix, Micro PDF417,
Truncated PDF417, MAXI CODE
Driver Microsoft Widows XP / VISTA / 10
Windows CE, Linux, Android, Blackberry
Black mark Support black mark detection
H/W Spec. MCU : 32bit RX, FLASH : 8M bytes, RAM : 16M bytes
Receive buffer size 1M bytes
MSR [option] ISO 7810/7811/7812, Triple tracks (1&2&3 Track Reading)
**Supports 3DES & AES encryption (3DES is standard) [option]**
**DUKPT key management**
Smart card reader [toption] ISO 7816 Compliant (EMV level 1 Certified) /
T=0, T=1 support / 1 SAM (Security Application Module)
LCD 128*32 Dots FSTN(Blue LED Backlight)
Battery Rechargeable 7.4V DC / 2,200mAh OR 2,600,Ah (Li-ion)
Battery duration 1 hour continuous printing
AC adapter ​Input(100~250VAC, 50~60Hz)​
Output(8.4VDC/0.8A), 4hours full charge time
Operating temperature -20°C ~ 55°C
Storage temperature -20°C ~ 70°C
MCBF(Mean Cycle Between failure) Mechanical 37,000,000 lines
Head Approximately 50Km

Applications

Field sales and service, Transportation, Hospitality, Parking, Utility billing, Safety, Material management.
